Chemistry Department Central Facility (CenFac)

Instrument Information

A vertical design with a high sensitivity balance and quick response furnace. The balance is located above the furnace and is thermally isolated from it. A precision hang-down wire is suspended from the balance down into the furnace. At the end of the hang-down wire is the sample pan. Static or dynamic, including nitrogen, argon, helium, carbon dioxide, air, oxygen, or other inert or reactive gases. Analyses done at normal or reduced pressures.

Brand:Perkin Elmer (M)

Model:Pyris 1 TGA

Location

FD-L1-45 MAKMAL TGA , Chemistry Lab Building.

Person In-Charge

Supervisor	Senior Science Officer	Senior Assistant Science Officer	Senior Assistant Science Officer

Name: Associate Prof.Dr.Norazilawati Binti Muhamad Sarih Designation:Associate Professor Telephone: +603-79677173 Fax: None Email: nmsarih@um.edu.my	Name: Miss Nur Izzati Abdol Rasul Designation:Science Officer Telephone: +603-79674067 Fax: None Email: n_izzati@um.edu.my	Name:Mr. Hashim Bin Mohammad Salleh Designation: Senior Assistant Science Officer Telephone:+60379674251 Fax: None Email: hashims@um.edu.my	Name:Ms. Nurul Ain Binti Hasani Designation: Assistant Science Officer Telephone:+603-79677022 ext.2118/2119/2520 Fax: None Email: ain88@um.edu.my

Sample requirement

Dry solid or liquid samples Sample weight: Approximately 20 mg

Instrument Handling Procedures

NIL

Limitation

Standard furnace - Temperature range: Sub-ambient to 1000 °C
Scanning rates: 0.1 °C/minute to 200 °C/minute
Temperature precision: ±2 °C
High temperature furnace - Temperature Range: 50 °C to 1500 °C
Sample mass range up to 1300 mg

Guideline to User on Sample Preparation

Standard furnace - Temperature range: Sub-ambient to 1000 °C
Scanning rates: 0.1 °C/minute to 200 °C/minute
Temperature precision: ±2 °C
High temperature furnace - Temperature Range: 50 °C to 1500 °C
Sample mass range up to 1300 mg

Application Form

Service Charge

For further information regarding service charges, please click;HERE

Thermogravimetric Analysis Brand Perkin Elmer
